Technical Specifications: SMPTE Standard Video bitrate: 3.2 GB/sec maximum; Interface: BNC Input and output cable specifications: 150m ( 1694A cable standard); Video input/output impedance: 75 Video input/output voltage: 1Vpp; minimum: 0.5Vpp/maximum: 1.5Vpp Differential gain (10%~90%): Less than 1% Specifications: SDI resolution 625/25 PAL, 525/29.97NTSC, 525/23.98 NTSC 720P@50,720P@59.94,1080i@23/24/30/50/59.94,1080P@23.98/24/30/50/60 Support SDI specification 270Mbps(SD-SDI), 1.485Gbps/M(HD-SDI) SMPTE425M3Gb/s mapping (3G-SDI) SMPTE424M 3Gb/s serial Interface: (3G-SDI) Fiber optic interface: LC Fiber type: single mode single fiber Wavelength: single mode 1310nm; 1550nm Maximum transmission distance Default: 3KM; Maximum: 20KM Power supply: DC 5~12V/1A Power consumption: Max 5W Temperature: Working temperature: -20~+70 Humidity: Working humidity: 0~90% Mean time between failures: 100000 hours Plug Type: US Plug, it applies to Canada, India, Mexico, Thailand, Taiwan, the , the Philippines and so on. Voltage: AC110V Material: abs colour: grey Package Contents: 1 x Fiber optic transmitter 1 x Fiber optic receiver 2 x Fiber optic module 2 x Plug Only the above package content, other products are not included. Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
