説明
Features:
1. RS485 (communication protocol Modbus-RTU) remote meter reading function.
2. Display and reading: electricity, current, voltage, frequency, power factor
3. Standard configuration pulse output passive (polarity), select remote pulse output passive (non-). It is easy to contact with various systems and conforms to the standards IEC 62053-31 and DIN43864.
4. Double color LED indicates the power status (green) and the energy pulse signal .
5. Automatically detect the flow direction and of the load current
6. One-way measurement of single-phase two-wire active power.
7. Direct S type connection
8. Extend the terminal cover to protect the use.
Specification:
Condition: 100% New
Model: DDM18SD
Voltage Specification: 220V
Frequency: 50Hz
Current Specifications: 5(100)A
Communication Method: RS485
Screen Display: Multi-function Cycle Display
Accuracy Level: 1.0
Working Temperature: -10 Celsius- +50 Celsius
Installation Method: DIN Rail Mounting
Communication protocol: MODBUS-RTU, DL/T645-1997, DL/T645-2007 (optional)
Weight: . 102g / 3.6oz
Colour:white
Material:plastic
Package Contents:
1 * DDM18SD Energy Meter
2 * Shell Accessories
1 * User manual
Small size, light weight and beautiful appearance
Good reliability and easy installation
35mm standard DIN rail mounting, in accordance with standard DIN EN50022.
Single pole width (modulus 18mm) in accordance with DIN43880.
The standard configuration 5+1 backlight LCD display (99999.1KWh)
-
ブランド:
Unbranded
-
カテゴリー:
電気計器
-
Fruugo ID:
434008064-910955684
-
EAN:
9039326774648
製品安全情報
以下に概説するこの製品に固有の製品安全性情報を参照してください。
以下の情報は、この製品を販売する独立したサードパーティ小売業者によって提供されています。
安全上の警告:
WARNING: Opening and/or repairing your device may result in risk of electric shock, damage to the device, fire and personal injury, and other hazards. We recommend that you seek professional assistance for device repairs and exercise caution when repairing your device yourself.
材料:
Other
