Features
1、Stable Fixing: The bullets terminal enables quick connection as well as firm fixing, suitable for 12‑10AWG wires.
2、Broad Utility: Allows for extensive use in electrical equipment, industrial automation, manufacturing and so on.
3、Good Material: Made of high strength copper, which is galvanized and tin plated for durability against corrosion.
4、With 25 Pairs: There are 50pcs crimp connector, that is, 25 pairs, and the quantity will meet your various needs.
5、Easy to Carry: Comes with a light weight and a compact size, both the storage and carrying are very convenient.
Specification
Item Type: Crimp Connector
Model: FRD5.5-195 MPD5.5-195
Material: Copper + PVC
Colour: Yellow
Applicable Wire: 4-6mm² (12-10AWG)
Maximum Current: 24A
Applicable Crimping Tool: HX-30J
Quantity: FRD5.5-195 female head 25pcs, MPD5.5-195 male head 25pcs.
Parameter:
Model W(Approx.) F(Approx.) L(Approx.) H(Approx.) d1(Approx.) D(Approx.) T(Approx.)
MPD5.5-195 5.0mm / 0.2in 9.0mm / 0.35in 24.0mm / 0.94in 13.0mm / 0.51in 3.5mm / 0.14in 5.6mm / 0.22in 0.4mm / 0.02in
Model Material Thickness(Approx.) b(Approx.) B(Approx.) D(Approx.) d(Approx.) F(Approx.) L(Approx.)
FRD5.5-195 0.4mm / 0.02in 4.0mm / 0.16in 7.7mm / 0.3in 4.5mm / 0.18in 3.4mm / 0.13in 7.3mm / 0.29in 25.5mm / 1in
Package List
25 x FRD5.5-195 Female Head Crimp Connector
25 x MPD5.5-195 Male Head Crimp Connector
-
Fruugo ID:
342491551-750477538
-
EAN:
6117160014021
製品安全情報
以下に概説するこの製品に固有の製品安全性情報を参照してください。
以下の情報は、この製品を販売する独立したサードパーティ小売業者によって提供されています。
製品安全ラベル
安全上の警告:
Please do not allow your child to handle this product alone to avoid swallowing or other injuries; adult supervision is recommended.
