! FNIRSI DSO152 Portable Digital Oscilloscope 200kHz MCX-BNC Adapter P6100 Probe The Fnirsi DSO152 is a compact digital oscilloscope that precisely analyzes both analog and digital signals, thanks to its real-time sampling rate of 2,5 MS or s and bandwidth of 200 kHz. It has trigger functions in 3 modes: single, normal and automatic, which provides flexibility in adjusting the oscilloscope to different signals. The meter is equipped with a 2,8-inch color display LCD, as well as a built-in rechargeable lithium battery, which provides users with efficient operation, ease of portability, and thus - better functionality. The Fnirsi DSO152 is charged via USB-C cable. The device will be great for people who appreciate handy devices and will find application e.g. during DIY, car repair or household appliances. It is perfect not only for buildings but also for outdoor use, providing precise measurements in a variety of conditions. Product Features: The maximum input voltage is 80Vpp using a 1:1 probe and, 800Vpp probe 1:10. 1KHz SQW calibration and one-button automatic adjustment Bandwidth up to 200kHz Sampling rate 2,5MSa or s Performs measurements of analog and digital signals Triggering in single, normal and automatic mode Possibility to change the triggering of the rising and falling slope It has an MCX connector for connecting the test signal It has additional functions such as mathematical measurements, one-button auto function It has a USB-C connector for charging and performing updates - Inner mesh panties Brand: Fnirsi Model: DSO152 Number of channels: 2 Bandwidth: 200kHz Max . input voltage: 80Vpp (1:1 probe), 800Vpp (1:10 probe) Measurement: 8 different parameters automatically Autoset function: Yes Sampling frequency: 2,5MSa or s Display: color 2,8" 320x240 LCD Battery: Li-ion 1000mAh Working time: approx. 4h (when fully charged) Functions of trigger: single, normal, automatic MCX connector for connecting wires: Yes Vertical sensitivity: 10mV or dz - 20V or dz in steps 1-2-5 Time base adjustment: 10us or dz - 50s or dz in steps 1-2-5 SQW frequency calibration: 1kHz Coupling modes: AC or DC or GND Charging voltage: 5V or 1A USB Input Impedance: andgt 1MΩ Dimensions: 99x68x20 mm Weight: 100g The set includes: Oscilloscope DSO-152 Measuring cable USB cable INFORMATION! The colors in the photos may differ from those in reality due to the type, intensity and angle of incidence of light, as well as depending on the monitor settings.
