Electronic Microscope Camera 4K Recording 8MP Image USB Digital Electronic Eyepiece with 1X C Mount Adapter Item Type: Electronic Microscope Camera Material: Aluminum Alloy HY800C Electronic Eyepiece Parameter: Image Sensor: 1/1.8 inch color image sensor, pure hardware 8MP image sensor, no compression, no interpolation Spectral Response: 400nm to 1000nm Resolution: 3840x2160; 2592x1944; 2560x1440; 1920x1080; 1280x720; 640x480 Dynamic Range: 74dB (linear) to 85dB (HDR) White Balance: Auto manual Signal to Noise Ratio: 39dB Scanning Method: Progressive scan Pixel Size: 2μm (H) x 2μm (V) Output Image Format: MJPEG YUY (UVC) Sensitivity: 2400 mV/Lx sec Image Output: USB 2.0, 480Mb/s One Key White Balance: Support Support Driver Free Protocol: USB Video Class (UVC) Support OTG Protocol: USB 2.0 OTG Adjustable Save Parameters: Brightness; Contrast; Color Saturation; Hue; Clarity; Gamma; Gain; White Balance; Backlit Contrast; Exposure Output Formats: 12/10 bit RAW RGB; Supports 2x2 binning; ISP clock up to 240MHz System Support: for Win XP 7 10 11, for Linux, for Android (compliant with UVC protocol); for OS X 10.4.8 or later (compliant with UVC protocol) Video Recording: 3840x2160 at 25fps; 2592x1944 at 25fps; 2560x1440 at 45fps; 1920x1080 HDR at 60fps; 1280x960 HDR at 60fps; 1280x720 HDR at 60fps; 640x480 HDR at 60fps; 320x240 HDR at 60fps; 3840x2160 at fps; 1280x720 at 5fps; 1920x1080 at 5fps; 640x360 at 3fps; 640x480 at 30fps; 320x240 at 30fps 1X C Mount Adapter Parameter: This is a 1X C mount optical adapter for microscopes using CX optical ports, including some SM series stereo microscopes and updated T490 series microscopes. This adapter allows the use of cameras with large image sensors (1 inch level). Camera Sensor Compatibility: 2/3 to 1 inch Compatibility: New stereoscopic microscope SM745T (non V203 or V331) T490 Camera Bracket: C mount bracket (1in/25mm diameter) Adapter Type: C type mount adapter Camera Connection Size: Approx. 25mm/1in (C type mount) Microscope Connection Size: Approx. 38mm/1.50in Adaptor Application: C Mount
